Mendota's new Engine has been delivered

2010 HME / Alexis

 Technical Specs
• HME Spectr MFDxL 12” raised roof Chassis
• Cummins ISL 400-HP Diesel Engine
• Allison 3000EVS Automatic Transmission
• Heavy Duty 3/16” Aluminum Body with ROM Roll Up Doors
• 1000-Gallon Poly Tank with 30-Gallon Foam tank and one (1) 2 ½” tank fill
• Hale QMAX150, 1500-GPM Pump with top operator’s controls
• Four (4) 2 ½” Discharges, two (2) left side, one (1) right side and one (1) rear
• One (1) 4” Discharge, right side and one (1) 3” Discharge, on deck over pump
• One (1) 2 ½” Mattydale Preconnect and two (2) 1 ½” Cartridge lay Preconnects
• One (1) Akron Deckmaster Deck Gun with fog/stream nozzle and remote control
• Waterous Advantus 6 Foam System and one (1) 2 ½” Gated Suction
• 24” Bumper Extension with 1 ½” Preconnect, center hose well and 5” Suction
• EMS compartment with three (3) adjustable shelves and ROM Roll Up Door, cab
• Three (3) Triple Air bottle compartments, two (2) right side and one (1) left side
• Zico Hydraulic Ladder Rack with suction hose and pike pole storage
• Custom backboard/pike pole compartment and hinged tool board
• Turtle Tile on floor and shelves/trays of compartments
• Sigtronics Intercom System and one (1) Audiovox color back-up camera
• Single Bank 4500-PSI Cascade System
• Kussmaul 1200 Pump Plus battery charger/air compressor and Auto Eject
• One (1) GOLIGHT 12-volt 65-watt Roof mounted spotlight with remote
• Four (4) Whelen Scene lights, one (1) each side of cab and two (2) rear
• Smart Power 10,000-watt hydraulically driven generator with 120-volt system
• One (1) Fire Research 120-volt 750-watt Brow light, cab roof
• One (1) Akron Electric Cord Reel and one (1) Hannay Hydraulic hose reel, rear
• Three (3) Fire Research Optimum recess mounted 120-volt 750-watt lights
• One (1) Tempest Light Tower with four (4) 1000-watt Fire Research lights
• Federal Electronic Siren with Cast Products 100-watt speaker
• Q2B Mechanical Siren and Two (2) Air Horns, front
• Whelen LED Warning Light Package
• 10’ 3” Overall height
• 34’ 1” Overall length
• 218” Wheelbase
• 158” Cab to Axle
• 18,000 FAWR
• 27,000 RAWR
• 45,000 GVWR

Body pictures can be viewed here (updated 8/5/2010)

Cab and Chasis Pictures   Cab and Chassis is complete and no new pictures will be added to this slideshow.

The Fire Department would like to thank the following people for pictures of the truck during the building process.
